High Intensity 4 mdes i cure Dental LED Curing Light

Short Description:

I-cure Dental LED Curling Light:

3 mode: Full/Pulse/Ramp

Intensity: 1800Lux

F.O.Light Guide: 10mm(dia.)

Light Wave Length: 420-480nm


Product Detail

Product Tags

number (9)
I-cure Dental LED Curling Light:
3 mode: Full/Pulse/Ramp
Intensity: 1800Lux

F.O.Light Guide: 8mm(dia.)
Light Wave Length: 420-480nm

One qualified dental curing light helps you make perfect filling

Turbo: 2500mW/cm2

Full/Ramp/Pulse: 1500mW/cm2

Time: 1s, 3s, 5s, 10s, 15s, 20s

Color: Light blue/white/purple

number (7)

Specifications

F.O.LIGHT GUIDE 10mm(dia.)
LIGHT WAVELENGTH  385-515nm
APPLICATION General
MODE P1 Turbo, 2300-2500mW.cm2 for 1, 3 seconds
P2 Full, 1400-1600mW.cm2 for 5, 10, 15, 20 seconds
P3 Ramp, 1st five seconds from 1500mW.cm2 next 5, 10, 15, 20 seconds 1400-1600mW.cm2
P4 Pulse, 1400-1600mW.cm2 for 5, 10, 15, 20 seconds(with 1 second blink in between)

Dental LED Curing Light Mode Applications

P1 1s for pre-cure & 3s for fast cure
P2 For general applications
P3 First 0-5 seconds are ramped for general application
P4 For more gentle processing, designed for patients sensitive to heat

Depth of Cure

MODE Intensity mW/cm Time Depth Measurements ISO 4049 Depth Measurements(-50%)
P1 2300-2500 3 seconds 4.5mm 2.25mm
P2 1400-1600 10 seconds 5.1mm 2.55mm
P3 1400-1600 10 seconds 4.9mm 2.45mm
P4 1400-1600 10 seconds 4.7mm 2.35mm
